Water Injected Screw Type Air Compressor 22KW Atlas Copco S AQ 22 VSD Oil Free

Water Injected Screw Type Air Compressor 22KW Atlas Copco S AQ 22 VSD Oil Free

Water Injected Screw Type Air Compressor 22KW Atlas Copco S AQ 22 VSD Oil Free
Water Injected Screw Type Air Compressor 22KW Atlas Copco S AQ 22 VSD Oil Free

Large Image :  Water Injected Screw Type Air Compressor 22KW Atlas Copco S AQ 22 VSD Oil Free Get Best Price

Product Details:
Place of Origin: China
Brand Name: Atlas
Certification: ISO 8573-1 CLASS 0
Model Number: AQ-22 VSD
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: as atlas corp standard
Delivery Time: 7-30 days
Payment Terms: T/T, Western Union
Supply Ability: 1000 pcs per month
Detailed Product Description
Material:: Aluminum Alloy Model:: AQ-22 VSD
Brand:: Atlas Copco Type:: Oil-free
Noise Level:: 70 DB(A) Application: Medical, Pharmaceutical Production, Food Production, Electronic Products, Etc
High Light:

Water Injected Screw Type Air Compressor

,

Screw Type Air Compressor 22KW

,

VSD Water Injected Screw Compressor

22KW ATLAS COPCO AQ-22 VSD OIL-FREE WATER INJECTED SCREW COMPRESSORS



POWERFUL OIL-FREE AIR
When it comes to clean, oil-free compressed air, you cannot afford to compromise on quality. Over the past decades, Atlas Copco has pioneered
oil-free water-injected screw technology, resulting in a broad range of compressors delivering 100% oil-free, clean air. Setting the standard through
ISO 8573-1 CLASS 0 certification, the AQ meets your need for pure oil-free air while offering best in class energy efficiency.



Water-injected screw element
• Highly energy-efficient thanks to low temperatures.
• Water-lubricated, grease-free bearings.
• In-house design and manufacturing.
• Working pressure up to 13 bar.



Water filter
• Ensuring a constant supply of clean water.
• The filtration capability equals 10 micron throughout the filter’s lifetime.

22kw Atlas Copco Water Injected Screw Compressors AQ 22 VSD Oil Free 022kw Atlas Copco Water Injected Screw Compressors AQ 22 VSD Oil Free 1

Elektronikon ®Graphic
Advanced Elektronikon ®Graphic control and monitoring system, designed for integration in a (remote) process control system.



Sound insulated canopy
No separate compressor room is required as the sound insulated canopy allows for installation in most working environments.



Electronic no-loss water drain
• Ensures constant removal of condensate.
• Manual integrated bypass for effective condensate removal in case of power failure.
• Integrated with compressor’s Elektronikon ® with warning/alarm features.



PROVEN TECHNOLOGY
At the heart of the new AQ range is a unique water-injected screw element working highly efficient near isothermal compression. The polymer ceramic rotors with their optimized rotor profile are supported by water-lubricated bearings, ensuring that no oil whatsoever can contaminate the compression element, thereby producing pure oil-free air.

22kw Atlas Copco Water Injected Screw Compressors AQ 22 VSD Oil Free 2
Rotors
A highly efficient compression process is achieved thanks to high quality polymer mould ceramic rotors with optimum profiling. The combination
of corrosion-free, high efficiency raw material and water lubrication results in a longer lifespan.


Element housing
Strength and durability are ensured as a result of the aluminium bronze element housing without risk of corrosion within the element.


Element bearings
The use of hydrodynamic bearings ensure long life as no physical contact is made within the bearing itself, it simply glides on a film of water removing the need for any oil or grease lubrication.



Specifications



COMPRESSOR
TYPE
Tyoe Max. working pressure
(bar(e)/psig)
WorkPlace
Capacity FAD* Installed motor power Noise
level**
Weight
WorkPlace
Weight WorkPlace
Full Feature
pack Full Feature l/s m³/min cfm kw dB(A) kg kg
AQ22 VSD air-cooled 13/188 12.75/185 22-66 1.3-4.0 47-140 22 70 740 / 1631 800 / 1764
water-cooled 13/188 12.75/185 22-66 1.3-4.0 47-140 22 70 740 / 1631 800 / 1764


(2) Mean sound pressure level according to ISO2151, uncertainty 3 dB(A).
(1) Unit performance measured according to ISO1217 Annex E, Edition 4, 2009.

22kw Atlas Copco Water Injected Screw Compressors AQ 22 VSD Oil Free 3
